Maytag® Top Load Electric Dryer with Steam-Enhanced Cycles - 7.0 cu. ft. YMED5430MW
Maytag
Maytag® Top Load Electric Dryer with Steam-Enhanced Cycles - 7.0 cu. ft. YMED5430MW
Specifications
Country Of OriginUSA
Top Load MatchingYes
Front Load MatchingNo
Required AccessoriesW10044609A, W10623830
Optional Accessories3406839
Extended Service Plan ParentEW03IW4Y, EW03IW2Y, EW03IW1Y
Product To Product PairsMGD5430MW, MVW5430MW
Electrical
Hz60
Volts240
Amps30
Certifications
ULYes
Energy Star QualifiedNo
Configuration and Overview
Fuel TypeElectric
Controls
Control LocationRear Console
End Of Cycle SignalYes
Control TypeKnob & Buttons
Feedback Status IndicatorsCool; Damp; Done; Sensing; Wet; Wrinkle Prevent
Features
LP ConvertibleNo
Sound PackageNo
Automatic Dry ControlYes
Moisture SensorYes
Pedestal OptionsN/A
StackableNo
Lint Filter IndicatorNo
Details
Hoses IncludedNo
Drum MaterialPowder Coat
Drying RackNo
Quad BafflesYes
Lint Screen LocationTop
Installation Considerations
Long VentNo
Maximum Vent Length Ft64
Venting DirectionRear Only
VentlessN/A
Options
Number Of Dryer Options4
Dryer Option SelectionsExtra Power; Temperature; Wrinkle Prevent; Wrinkle Prevent w/Steam
Compatibility
Works With
Exterior
Door StyleSide Swing
Reversible DoorYes
WindowNo
Temperature Settings
Number Of Temperatures4
Temperature SelectionAir Only; High; Low; Medium
Cycles and Options
Cycle Time RemainingNo
Cycles
Number Of Dryer Cycles10
Drying Cycles Selections45 min Dry; 60 min Dry; 90 min Dry; Air Only (90 min); Bulky Items; Casual; Delicates; Normal; Steam Refresh
Carton Depth30.0"
Carton Height44.0"
Carton Width31.0"
Depth With Door Open 90 Degree51.0"
Depth28.25"
Gross Weight125.0 lbs.
Height43.0"
Maximum Height43.0"
Minimum Height39.0"
Width29.0"
Capacity IEC CAN (cubic feet)7
